Alta Modern Gate Latch for Out-Swinging Gates
(Reverse Setup)
**This is a special setup is for out-swinging gates where you want the latching arm on the inside of the gate. See the animation below for how it all goes together. If you have an out-swinging gate, but want the latch arm on the exterior of the gate (typical setup), see this product instead.
We designed this latch to work with out-swinging gates where you don't want to see the latch on the exterior of the gate. Set includes gate latch, strike plate, and gate stop.
There are three key factors to make this work:
- Must have a 1/2" gap between the gate and the post.
- Gate latch installed at a 2-3/8" backset
- Install gate stop to assure alignment (gate stop included in set)
The Alta is a two-sided latch, operable from both sides.
If you're looking for a modern lever gate latch, this stainless steel gate latch is ideal for coastal locations. The Alta Latch is crafted of 316 Stainless Steel for the best protection against the elements. The lever handles are spring-loaded for smooth operation, so it works not just for contemporary gates, but also for pool gates because it's self-latching. This gate latch is precision-machined for flawless function.
When you've put the effort and expense into designing and building a unique modern or contemporary wooden gate, you need a modern gate latch to complement the design. The Alta Latch is that gate latch!
The Alta Latch fits gates up to 5-1/2" thick; specify gate thickness with order.
What if I don't know the exact thickness of my gate yet? If you don't know the exact thickness of the gate, please overestimate. The metal rod connecting the handles through the body of the gate can be cut down on-site by your installer.
Gate swing direction and exact gate thickness required with order. If you're ordering for a double gate, please note the swing direction for the moving gate (not the fixed gate).
The Alta Contemporary Lever Latch is proudly made in Portland, Oregon, USA. Your purchase supports a small business and we appreciate it!
Details of this contemporary gate latch
-
Material: 316 Stainless Steel
-
Mechanism: Spring-Loaded
-
Finishes available: Brushed Stainless
-
Set includes mounting hardware, strike plate, gate stop
-
Fits gates up to 5-1/2" thick.
-
Operable from both sides.
-
Suitable for out-swinging gates.
-
Handing required with order
-
Backset: 2-3/8"
-
Lockable with added deadbolt.
Dimensions of this stainless steel latch
- Plate: 3-1/2"w x 4-1/2"h
- Handle: 4-3/4"l x 3/4"w x 3/4"d
- Latch-arm length: 1" from edge of plate
- Strike: 2-1/8"h x 2-3/8"w x 3/8" thick
- Handle Projection: 2-3/8"
Options
Locking
- We offer a coordinating brushed stainless steel deadbolt for a complete ensemble. Deadbolts are available in either single or double cylinder, depending on your needs.
- For any gate over 2-1/8" thick (for single cylinder) and 1-7/8" thick (for double cylinder), you'll need to add an extension kit.With an extension kit, the single cylinder deadbolt fits gates up to 2-3/4" thick, while the double cylinder deadbolt will fit gates up to 2-1/4" thick.
- We've also added a Deadbolt for Thick Gates and Doors that will accommodate doors and gates up to 5-1/2" thick.
Hinges
- We offer a set of three 4x4 stainless steel (grade 316) heavy duty butt hinges that complements the latch well.
Technical Info
Hardware Tips
Maintenance
Resources
Watch this video to see a quick run-through of the installation.FAQs
Read our FAQs for additional information about various products and policies.
Take a look at the Answering Customer Questions section of our blog for a deeper look at same of our product types and manufacturers.
Product Images
We're always looking for new photos of our hardware installed on your projects! Send us your photos for a chance to win $100 off your next order!
Warranty
360 Yardware warrants this hardware to be free of defects in material and craftsmanship for two years from the original invoice date.Returns
This product can be returned in its original condition (original packaging intact, uninstalled, can be put back on the shelf directly) with a 10% restocking fee. If any effort is required to repackage or review the hardware, the restocking fee will be 25%. Customer responsible for return shipping. To initiate return, please complete the Return Form. Initiate a Return NowAdd A Dummy Handle for Double Gates?
If you have a double gate, it’s an option to add a dummy handle to the outside of the inactive gate. The dummy handle gives a ‘finished’ and symmetrical look to the gates and provides a handle to pull and push the inactive gate with. For gates that will be used frequently by people who aren’t familiar with the gate: dummy handles can also cause confusion because a visitor doesn’t know which handle is operable.Add A Gate Stop?
A gate stop is needed on all gates. The stops that we have are attached to the gate and catch on the post when the gate is pushed closed. The stop maintains the proper alignment so that the latch can latch, but won’t be damaged if the gate is slammed.
Add Jar of Touch-Up Paint
Each cranked band strap hinge comes with a carriage bolt, which is installed through the hinge and through the door/gate. These bolts have a silver finish. At installation, you can paint the carriage bolt’s head black with optional touch-up paint.Add Cane Bolt?
A cane bolt is needed when you have a double gate set. The cane bolt holds the inactive gate down to the ground. It can also be used to hold a gate open. Sometimes two cane bolts are used on double gates (one on each gate) so the gates can be held open (in the case of a driveway gate, for example).Backset
The backset is the distance from the edge of the door or gate to the centerpoint of the through-hole of the hardware. Dummy handles do not require a backset.
Cylinder
Deadbolts can be either “single cylinder” or “double cylinder”. Single means there is a key hole on the outside and a thumbturn on the inside. Double means there is a key hole on both sides of the deadbolt.
Door thickness
Refer to the range of acceptable thicknesses on the product description, and then choose your door’s thickness. Try to choose a thickness within 1/8” of your actual thickness.Dummy Side
When you need a dummy handle, you’ll need to choose which side to order. There are two options: Left and Right. Refer to the image below to determine your dummy handle.
Extension Kit for Gates up to 3.5"
These latches fit gates up to 2-1/2” with the standard tongue. With the addition of an extended tongue piece, you can fit a gate or door up to 3-1/2” thick.Gate Thickness
Refer to the range of acceptable thicknesses on the product description, and then choose your gate’s thickness. Try to choose a thickness within 1/8” of your actual thickness.Hinge
A number of hinge options are available. Butt hinges work on gates that are ~6 feet high and 42” wide. A thicker gate can use a bigger butt hinge than a thinner gate. If the gate or door is wider than 48”, you should choose a strap hinge.Interior Door Function
When you need a dummy handle, you’ll need to choose which side to order. There are two options: Left and Right. Refer to the image below to determine your dummy handle.- Passage Function: Passage or Hall and Closet Lever Handles are used on doors that do not require a locking mechanism. Halls, closets, pantry or laundry doors will generally use a passage leverset. Passage levers do not have a locking mechanism.
- Privacy Function: Privacy Hardware are most often used on Bedrooms, Baths or Office doors where a lock for privacy while occupied is desired, but a keyed lock is not really necessary. Emtek privacy levers have a push button on the rosette or backplate as shown to the left to activate the lock. On the outside, there is a pin hole for emergency unlocking. Some levers will have a pin hole inside a circular piece, some just have a small pinhole.
- Dummy Function: Emtek Double Dummy Door Knobs are sold in pairs. Dummy knobs do not have a latch or mechanism of any kind. These door knobs are surface mounted to a door that has not been bored (large hole cut out). Dummy knobs are generally used on double doors that us a ball catch at the top to keep them closed so a latch is not required. They are also commonly found on the inactive side of a french door - a single dummy mounted on either side of the inactive door.
Key All Deadbolts Alike?
If you’re ordering two or more deadbolts, you have the option to use the same key for both, so that you don’t have to use separate keys. If you’re ordering one deadbolt choose “Single Lock or Not Keyed Alike.”Mortise Lock Type
Rosette Style
The rosette is the plate portion of your hardware. Choose the rosette that works best for the style you desire.Screw Shape & Length
Hex head screws are made of stainless steel and finished dark to coordinate with the hardware. Square head screws are made of a rust-resistant material (not stainless) and finished dark to coordinate with the hardware. If you’re in a coastal area, choosing the hex head fasteners is the best choice.Standing in Front of the Gate, Which Way Does It Swing?
This gate latch is handed one direction or the other. For single gates, you can answer the handing questions from either side of the gate as long you answer both questions standing in the same position. For double gates: answer the handing question for the active gate (the one that will have the latch installed).Standing in the same position, what side is the gate hinged on?
This gate latch is handed one direction or the other. For single gates, you can answer the handing questions from either side of the gate as long you answer both questions standing in the same position. For double gates: answer the handing question for the active gate (the one that will have the latch installed).Type of Strike
Surface strike: will be installed to the face of the post (or the face of the second gate if this is a double gate).
Mortise strike: will be installed the inner edge of the post (or the edge of the second gate if this is a double gate).
