Full Mortise Stainless Steel Heavy Duty Ball Bearing Hinges
4.5" x 4.5" Square Corners (Set of 3)
Ball Bearing Hinges are excellent for larger-sized or heavier doors and gates. The Ball Bearings allow an easier swing and will help prevent the sag that using an inadequate hinge sometimes causes.
This stainless steel ball bearing hinge has a stainless steel pin. Fasteners are included. #12 x 1-1/4" size (This hinge is provided with 1-1/4" long screws. You may want to substitute your own longer screws to grab deeper into the wood. The spec to ask for at the hardware store is #12 made of 18-8 stainless x whatever length you need.)
A stainless steel hinge is the right choice for coastal locations and corrosive environments.
A set of three holds a weight of 125lbs. Mounting screws included. Made of Stainless Grade 302/304. These are commercial-grade hinges.
This hinge can be installed directly to the surface edge of the gate and edge of the post, or can be mortised for a more finished look. For surface-mounted installations, allow a 5/16" gap between edge of gate and post. For mortise installations, allow a 1/16" to 1/8" gap between edge of gate and post.
.png)
Options
Please find links to where you can purchase different sets in the Alternate Configurations section below.
Alternate Configurations
- 4.5"x4.5"Stainless Steel Heavy Duty Ball Bearing Hinge (Pair)
- Stainless Steel Heavy Duty Ball Bearing Hinge (3) -Up to 110lbs
- Stainless Steel Heavy Duty Ball Bearing Hinge (3)-Up to 110lbs
- Stainless Steel Heavy Duty Ball Bearing Hinge (3)-Up to 125lbs
- Stainless Steel Heavy Duty Ball Bearing Hinge (Pair) -Up to 75lbs
- Stainless Steel Heavy Duty Ball Bearing Hinge (Pair)-Up to 75lbs
- Stainless Steel Spring Hinge ComboSet of 3 Hinges (up to 85 lbs)
