12" Stainless Steel 316 Cranked Band Hinges
A Lift-Off Hinge in Satin Stainless Finish
This pair of stainless steel strap hinges is a terrific option when you're looking for a clean, contemporary hinge. These hinges can be used for carriage house doors, shed doors, or gates. they fit doors and gates with a maximum thickness of 5".
In the square hole on the strap, you insert the included stainless steel (grade 18-8) carriage bolt for additional rigidity to the installation (a through-bolt).
This is a called a lift-off hinge because once installed, the gate or door can be lifted off the pintles if needed. If you'd like to prevent the gate being lifted off, simply install the upper pintle facing down.
These stainless steel hinges are made of marine grade 316 stainless which offers the best in rust resistance. The carriage bolt is also a stainless finish.
Details for this strap hinge hardware:
Material: 316 Stainless Steel
Finishes available: Satin Stainless
Set includes mounting hardware, including stainless steel carriage bolt (with nuts and washers) and #12 x 2" stainless steel wood screws
Fits gates and doors up to 5" thick
Suitable for in-swinging and out-swinging gates, but the hinges must be installed on the side of the gate that it opens toward.
Sold as a pair (two pintles + two straps).
Dimensions of this stainless steel hinge:
- Strap Hinge: 12"l x 1.5"h
- Pintle: 5.25"h x 1.5"w x 1/2"diameter.
- Select the thickness of the gate this will be installed on.
Please find links to where you can purchase different sizes and quantity sets in the Alternate Configurations section below.
To learn more about stainless steel hardware, care, and maintenance, visit our help page.
Please review our Resources page for general information about all our products.
